CompAir C105-14

Reliable, fuel efficient Deutz engines of series 1013.

Energy saving compressor screw block machined with smallest tolerances, progressive volume flow regulation: Engine speed and air intake regulation are automatically adapted to compressed air requirement.

Corrosion resistant, galvanized canopy sheet metal with lasting baked powder coating.

Quick replacement of the individually bolted canopy panels, e.g. in case of accidents.

2 large and wide angle upwards opening side wing doors supported by gas struts offer easy access to the maintenance points.

Additional front door for coolers maintenance.

Elastic polyurethane mudguards to withstand rough handling on site.

Easy to access and to read instrument panel.

Inside battery main switch avoids unauthorized operation.

Start by rotary switch to avoid loss of time caused by lost ignition key.

Pilot lamps for automatic emergency stop in case of malfunction.

Automatically shut down when the following faults occur: – charge control (e. g. rupture of v-belt, defective dynamo) – engine oil pressure too low – cooling water level too low – cooling water temperature too high – pre-compressed air temperature too high – compressor oil temperature too high – water present in fuel pre-filter.

Automatic shut-down in case of lack of fuel with alarm lamp preventing from expensive running empty of tank and bleeding of fuel system.

Transparent plastic fuel tank for direct visual level and pollution checking.

Large fuel filter with water separator an manual filling pump increases operation reliability.

Air end with spin-on oil filter cartridge, easy to replace.

Central lifting eye for easy handling by crane.

The unit has been provided with a 24 V electric system. This ensures sufficient power reserves in case of cold starts and a safe run-up ability
